Textile Digital Printer · High Capacity

NKT F1218 Series

A high-capacity textile digital printer series - 1800mm to 3200mm width, with printing capacity up to 2731 m²/hr.

Kyocera EX600 / KJ4B printheads - sold & serviced by Apsom

Max printing width 1800mm-3200mm across the series
Up to 2731 m²/hr (F1232, 48-head KJ4B, 1 pass)
Independent constant tension cloth delivery
Pan-India installation & AMC support included

Request a Quote Download Brochure

Technical Specifications

Built for the production floor.

Model Range	F1218 / F1226EX / F1232EX
Max Printing Width	1800mm (F1218) / 2600mm (F1226EX) / 3200mm (F1232EX)
Number of Colours	8-10 colour
Operating System	Windows 10, 64-bit
RIP Software	Neo Stampa
Printing Capacity (F1218, 96-head, 1 pass)	1817 m²/h
Printing Capacity (F1226EX, 96-head, 1 pass)	2290 m²/h
Printing Capacity (F1232, 96-head, 1 pass)	2572 m²/h
Installed Power	42.9kW - 61.6kW depending on model
Weight	9000kg - 12000kg

All specifications are subject to change without notice. Confirm exact figures with an Apsom specialist before ordering.

Standard Configuration

High capacity, constant tension delivery.

Independent Constant Tension

Cloth delivery machine keeps fabric feed consistent.

Movable Press Unit

Consistent fabric contact for accurate printing.

Head Protection Mechanism

Guards heads during idle and maintenance periods.

Auto Head Cleaning System

Automatic maintenance for consistent output.
