Computer-vision guided printing for accurate placement on embroidered, lace, and jacquard fabrics - with Ricoh Gen6 printheads.
| Configuration | 16 heads (8 colour) |
| Printing Speed (2-pass) | 600×600 dpi, 240 m²/h |
| Printing Speed (3-pass) | 600×900 dpi, 180 m²/h |
| Printing Speed (4-pass) | 600×1200 dpi, 120 m²/h |
| Max Print Width | 2000mm |
| Max Fabric Width | 2020mm |
| Ink Type | Acid, reactive, disperse - all compatible |
| Colour | CMYK, Orange, Grey, Blue, Red |
| Working Environment | 18-30°C, 35-80% humidity (non-condensing) |
| Overall Size | 4220×2040×2000mm |
| Weight | 1500kg |
All specifications are subject to change without notice. Confirm exact figures with an Apsom specialist before ordering.
Combines embroidery texture with vibrant digital colour and detail.
Prints accurately within lace contours for high-grade lace production.
Precise positioning of small letters and intricate contours.
Expands colour palette with accurate contour printing.
Tell us about your production needs and an Apsom specialist will get back to you - typically within 1 business day - with pricing and availability for the Precision Digital Textile Printer - Position Printing.
